EliteSuite 4-Zone Condominium LCD Keypad

Brand : ICT

UPC : 685225102519

PART # : ELT-KLCD

Supports up to 8 local user codes
Stay, Force, and Instant arming modes
Activation of three reportable panic events: panic, medical, and fire
Individual reportable duress code assigned to each LCD keypad
Two inputs (expandable to four using duplex mode) for alarm and automation functions, expandable up to 16 inputs using slave keypads
One programmable multi-function output
Fire zone functionality

Operating Voltage 11VDC to 14VDC

Operating Current 38mA (59mA Max)

User Interface Display Energy smart backlit LCD 16 x 2 alphanumeric display with enhanced viewing angle

User Interface Keypad Clavier multifonction à 12 touches avec membrane en silicone, rétroéclairé à faible consommation

Indicateurs Armed, LED Ready and LED Beeper

Inputs 2 standard or 4 using Input Duplex mode

Outputs 1 open collector (50mA Max) output. Programmable for all output functions

Dimensions (H x W x D) 126 x 139 x 24mm (4.96 x 5.47 x 0.9”)

Weight 318g (11.21oz)

Operating Temperature 5˚ to 55˚C (41˚ to 131˚F)

Storage Temperature -10°- 85°C (14° - 185°F)

Humidity 0%-93% non condensing, indoor use only (relative humidity)

No documentation for this product yet.
