Image Sensor
1/2.8” Progressive Scan CMOS
Minimum Illumination
Color: 0.006 Lux (F1.6, AGC on), 0 Lux with light
Illumination Distance
IR: up to 40 m
Smart IR
Supported
Strobe Light
Supported
Pan / Tilt / Rotation
0° to 360° / 0° to 75° / 0° to 360°
Focal Length
2.7 ~ 13.5 mm
Aperture
F1.6
Field of View
HORIZONTAL: 108° to 34° / VERTICAL: 58° to 19° / DIAGONAL: 130° to 39°
Mount
Φ14
DORI
D: 93 - 274 m / O: 36.3 - 108.1 m / R: 18.2 - 54.4 m / I: 9.1 - 27.2 m
Video Compression
H.264 / H.264+ / H.265 / H.265+ / MJPEG (sub stream)
H.265 Codec Profile
Main
H.264 Codec Profile
Base / Main / High
Video Bit Rate
11 Kbps to 16 Mbps
Multiple Streams
Triple streams
Audio Compression
G.711A, G.711U
Audio Bit Rate
64 Kbps
Maximum Resolution
8MP (3840 × 2160)
Main Stream
50Hz: 25 fps 8MP (3840 × 2160); 25 fps 6MP (3200 × 1800); 25 fps 5MP (3072 × 1728); 25 fps 4MP (2560 × 1440); 25 fps 1080P (1920 × 1080) // 60Hz: 30 fps 8MP (3840 × 2160); 30 fps 6MP (3200 × 1800); 30 fps 5MP (3072 × 1728); 30 fps 4MP (2560 × 1440); 30 fps 1080P (1920 × 1080)
Sub Stream
50Hz: 25 fps 720P (1280 × 720) ; 25 fps D1 (704 × 576) ; 25 fps CIF (352 × 288) // 60Hz: 30 fps 720P (1280 × 720) ; 30 fps D1 (704 × 480) ; 30 fps CIF (352 × 240)
Third Stream
50Hz: 25 fps CIF (352 × 288) // 60Hz: 30 fps CIF (352 × 240)
Parameters
Brightness / Contrast / Saturation / Hue / Sharpness
Shutter
Auto / Manual, 1/3 to 1/100000 s
Day / Night
IR Cut Filter
WDR
120 dB
Noise Reduction
2D / 3D DNR
Back Light Compensation (BLC)
Supported
High Light Compensation (HLC)
Supported
Region of Interest (ROI)
Supported
Rotation
Supported
Basic Events
Motion detection, video tampering
Smart Events
Smart motion detection, line crossing, area intrusion, region entrance/exiting with human/vehicle filtering
Face Detection
Supported
Loitering Detection
Supported
Scene Change Detection
Supported
Storage
NAS (NFS, SMB/CIFS), ANR
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P
Compatibility
ONVIF (Profile S, G, T), SDK
Security
Password protection, strong password, HTTPS encryption, IP filtering, HTTP/HTTPS authentication, TLS 1.1/1.2, WSSE
Users
40
Browsers
IE10, IE11 ; Chrome 57+ ; Firefox 52+ ; Safari
Mobile
iOS, Android
Red/Blue Light
N/A
Sound Warning
N/A
Network
1 × RJ45 10/100 Mbps
On-board Storage
Up to 256 GB
Microphone
Supported
Speaker
N/A
Audio Input / Output
1/1
Alarm Input / Output
1/1
Reset Button
Supported
Operating Conditions
-40 °C to 60 °C
Humidity
≤ 95% non-condensing
Power Supply
DC12V ± 25%
PoE
802.3af
Power Consumption
Maximum 11 W
Protection
IP67
Material
Metal
Dimensions
Φ144.5 × 113.5 mm
Weight
1100 g
