Operating Voltage
12VDC (9.5 to 14VDC)
Operating Current
165mA (peak, reading)
Card Read Range
MIFARE: 50mm (1.97") DESFire EV1 ISO: 5mm (0.2") DESFire EV2 ISO: 25mm (0.98") DESFire EV3 ISO: 20mm (0.79") 125kHz Clamshell: 45mm (1.78”) *
Tag Read Range
MIFARE: 25mm (0.98") DESFire EV1: 5mm (0.2") DESFire EV2: 5mm (0.2") DESFire EV3: 10mm (0.39") 125kHz: 25mm (0.98”) *
Wiegand Interface
Multiple format 26, 34, or 37, customizable, Bit data 0 and data 1, sent at 1kHz
Frequency
13,56 MHz ISO/IEC 14443 Type A* 125 kHz (porteuse, plusieurs formats de modulation pris en charge)*
Multi Conductor Cable
Module comms / RS-485: Belden 9842 or equivalent Max distance 900m (3000ft) Wiegand: 22 AWG alpha 5196, 5198, 18 AWG alpha 5386, 5388 Max Distance 150m (492ft)
OSDP Communication
OSDP standard 2.2 with Secure Channel Protocol
Bluetooth Read Range
Proximity mode: up to 0.5m (1.6ft) configurable Action unlock (shake): up to 5m (16.4ft) configurable
Bluetooth Electronic credential transmission technology
Bluetooth® version 5.1 compliant Proprietary data exchange protocol. AES-128 encrypted Credentials can be distinguished by unique site code and card number
Bluetooth Wireless Device
Protege Mobile 1.0.x
NFC Read Range
Up to 60mm*
NFC (Near-field communication) Electronic credential transmission technology
Android 4.4 or above, with phones which support ISO7816-4 Proprietary Secured DESFire credential Credential is AES-256 (NIST certified AES algorithm) Credentials can be distinguished by unique site code and card number
Appareil NFC
Protege Mobile 1.0.x
Indice de protection
IP65
Operating Temperature
UL/cUL -35° to 66°C (-31° to 151°F) : EU EN -40° to 70°C (-40° to 158°F)
Storage Temperature
-10° to 85°C (14° to 185°F)
Mean Time Between Failures (MTBF)
520,834 hours (calculated using RFD 2000 (UTE C 80-810) Standard)
Reader Dimensions (H x W x D)
117 x 43 x 9.5mm (4.6 x 1.7 x 0.37")
Reader Weight
Net Weight: 60g (2.1oz) Gross Weight: 100g (3.5oz)
